YLG-60 Full-automatic easy-pull can bottling production line
YLG-60 Full-automatic easy-pull can bottling production line Download Email Print this Page
Products Name :YLG-60 Full-automatic easy-pull can bottling production line
Specifications
I. Overview.

This production line is suitable for automatic canning and capping and labeling of nuts, candied fruits, melon seeds and other granular materials.

The production line is fully automatic from bottle management, automatic measurement and filling, sealing easy-to-open lids, pressing plastic lids,

 labeling and outputting finished products, which greatly saves manpower and improves production efficiency. According to customer's demand, it

can be equipped with coding mechanism, etc.



This production line consists of the following parts.
1、Bottle management machine
2、Combination scale
3、Rotary positioning feeding
4、Capping machine
5、Automatic capping machine
6、Capping machine
7、Round bottle labeling machine
8、Working platform
9、Turning bucket elevator


II. Performance characteristics.
1. Specially designed for product weighing and feeding, sealing, capping and labeling in one machine.
2. effectively improve the packaging structure, so that solid and liquid products are easy to use and beautiful packaging.
3. The front section uses empty cans and bottles, the middle section uses material weighing and feeding, sealing, and the back section uses labeling to end.

4. The automatic can bottle filling line solves the shortcomings of the old manual can machine such as difficult bottle management, unattractive sealing,

inaccurate feeding and incorrect labeling, and saves a lot of labor and improves production capacity.



Three, technical parameters.
Voltage specification: AC380V/AC220V 50/60HZ
Power consumption: 5.5W / hour
Weighing speed: 20-70 bottles / min (depending on the size and capacity of the bottle)
Sealing speed: 10-60 bottles / min (depending on the equipment single column or multiple columns)
Capping speed: 10-60 bottles / min (depending on the equipment single column or multiple columns)
Labeling speed: 10-100 bottles / min (depending on the bottle size or label length)
Applicable container range: 20-2000 grams (can be customized according to specific requirements)
Overall dimension: 8000*4600*3600mm
