Description. 1、Adopting automatic cup feeding and automatic cup stacking equipment, cup stacking is more accurate. 2、All adjustments are placed on the outside, making the operations more humane. 3、With precise ink temperature and quantity control system and "no cup, no print" operating system. 4、The application of corona treatment makes the printing process more scientific. 5、Have high efficiency UV curing system to make the ink dry more quickly and firmly. 6、The application of monitor for PLC electronic control, as well as digital display function system, so that the machine's various operations conversion more efficient.
Main technical parameters. Printing diameter: 4 sheets of rotogravure mode Φ30--Φ95mm. 2-sheet rotogravure mode Φ30--Φ168mm Max. printing height: 160mm Max. cup bevel angle: 12° Max. printing speed: 20,000 pcs/hour Cup rim diameter：Φ50--Φ190mm Cup height：30--180mm Main motor power：7.5kw Total power：19kw Machine size: 6000X2200X2080mm
