Toppan printing and cutting machine
Toppan printing and cutting machine Download Email Print this Page
Products Name :Toppan printing and cutting machine
Specifications
Application.

This machine is a printing machine with photopolymer soft plate as the plate material, commonly known as

"aniline printing machine". It is suitable for printing polyethylene, polypropylene plastic bags, cellophane,

paper rolls, non-woven fabrics and other packaging materials, and it is ideal for printing food paper and plutonium.

 This machine is ideal for printing food paper and coins, etc. When the printing is finished, it cuts off synchronously

 and automatically manages the paper.



Performance and characteristics.
1、Easy to operate, soft start, accurate color register.
2、The meter can set the printing quantity according to the requirement, and it will stop automatically when the number is reached, and it will stop automatically when the material is cut off.
3、Pneumatic lifting and lowering of printing plate cylinder, automatic ink stirring after lifting.
4、Anilox cylinder transmits ink, and the ink color is even.
5、Reliable drying system, with high speed operation, automatic break down after stopping.
6、360 degree continuously adjustable longitudinal alignment device.
7、Variable frequency speed adjustment, adapt to different printing speed.
8、The plate roller seat and the receiving frame are equipped with pointing and stopping buttons, which are easy to manipulate the machine when loading plates.
9. Unwinding tension is controlled by magnetic powder brake.
10. With automatic roller cut-off.
11. Automatic paper management device


Main technical parameters.
Model: JT-2600, JT-2800, JT-21000
Maximum printing width: 600mm, 800mm, 1000mm
Maximum printing width: 560mm, 760mm, 960mm
Print length range: 191~1000mm, 191~1000mm, 191~1000mm
Maximum coil diameter: ф450mm, ф450mm, ф450mm
Printing speed: 50~80m/min, 50~80m/min, 50~80m/min
Plate thickness (including double-sided plastic bags): 2.38mm, 2.38mm, 2.38mm
Total power: 8Kw, 10Kw, 12Kw
Machine weight: 1800kg, 2000 kg, 2200 kg
Overall dimension: 2300×1860×2145mm, 2300×2060×2145mm, 2300×2260×2145mm
