Main Technical Parameters
|
Model |
SW-1200 |
|
Coating Mode |
Micro-concave Roller Coating |
|
Coating Width |
1100mm |
|
Reeling and Unreeling Form |
Single-station |
|
Unreeling Diameter |
Ф1000mm |
|
Reeling Diameter |
Ф1000mm |
|
Length of Baking Oven |
21m |
|
Heating Mode |
Electric Heating |
|
Temperature of Baking Oven |
Normal Temperature -130℃ |
|
Working Speed |
10-80m/min |
|
Mechanical Speed |
100m/min |
|
External Dimension |
24000×3000×4200mm |
|
Machine Weight |
about 19000kg |
