Main technical parameters. Power supply: three-phase 380V,50HZ Total power: 105Kw (excluding glue machine and air compressor) Overall dimension (L*W*H): 20,000*2500*2700mm Design speed: 250-300 pieces/min Qualification rate: ≥96% (without glue machine, material reason)
Features and performance. 1. Can produce large, medium and small size products 2. Polymer mixing imposed 3. with powerful crusher 4. With elastic waistband, front waistband patch, side waistband patch, three-dimensional circumference, leg rubber band application mechanism 5. Tri-fold arrangement of output after forming 6. Broken material, lack of material detection alarm, change the material to receive the waste product rejection 7. The transmission system adopts a combination of closed gear box, universal coupling and synchronous belt, with high synchronization and stable transmission. 8. The product forming and positioning processes are all equipped with electric differential speed drives, which can be adjusted synchronously without stopping. 9. PLC + touch screen + frequency converter control system 10. Splicing device: each roll of material is equipped with a material end cutter, material splicing can be done manually or automatically.
