Maximum paper width

39.96’’ (1015mm)

Maximum printing width

39.37’’(1000mm)

Printing repeat

11’’-26’’(279.4-660mm)

Maximum unwinder diameter

60’’ (1524mm)

Maximum rewinder diameter

60’’ (1524mm)

Gearing

1/8CP ,teeth space3.175mm

Maximum mechanical speed

500fpm(152m/min)

Drive

11KW

Lubricating system

Automatic

Control panel

In the front of the press

Air pressure

100PSI(0.7Mpa)

Power requirement

380VAC 3ph  50HZ

Substrate

40-200gsm paper

Machine color

white
