Non-woven Fabrics making machine
Non-woven Fabrics making machine Download Email Print this Page
Products Name :Non-woven Fabrics making machine
Specifications
Introduce:
PRODUCT DIRECTIONS:
This production line is filament        polypropylene fiber spunbonded non-woven fabric equipment.Its raw material is polypropylene(pp),take the principle of spinning man-made fibres,duringpolymer filature,continuous filament is extended into fiber,during
which is finished by mechanical hot pressing.The machine assembly we adopt is now advanced veneer
integer slot air flow draw technology,the whole process from material feeding to cloth
output is automatic controlshort production flow,high working efficiency.The non-woven fabric we produce has high strength,good softness,innocuity,acterium-proof,corrosion
resistance,high-levek draw strength ans elongation rate.They are widely used for dress,
decoration materials,medical sanitation materials,daily life products and in the industrial,agricultural fields.In addition,
this production line can produce non-woven fabrics of different color,differen
grams,different lines according to ueses’demand
Width:1.6m,2.4m,3.2m,lines on non-woven fabric:dots,cross lines,straigh lines.

Explain:



Main Technical Variables:


Model

DL-1600

DL-2400

DL-3200

Diameter of screw

Φ105-Φ170

L/D

30:1

capability

1200

2000

3000

Max.film width(mm)

1600

2400

3200

Weight range(g/㎡)

10-200

Fiber number

2D-4D

Total power

280

450

600
