Multi-functional automatic cartoning machine

Multi-functional automatic cartoning machine Download Email Print this Page

Products Name :Multi-functional automatic cartoning machine

Bottom

Return

Specifications

Overview
This product is suitable for the packaging of pharmaceutical aluminum-plastic plates, medicine bottles, cosmetics, poker and similar items, and can automatically complete the folding of instructions, opening of cartons, loading of items, printing of batch numbers and sealing of boxes.
(Hot melt glue device can also be added)
The machine adopts PLC control and photoelectricity to monitor the action of each part, and if there is any abnormality in the operation, it can automatically stop and show the reason so as to eliminate the trouble in time.

Features
1. Product height is not standard, no manual automatically pick waste.
2. The product into the box is not in place automatically stop.
3. No carton, continuous no manual, no product automatic stop.
4. Easy to replace different product specifications.
5. The main drive has overload protection device.
6. PLC automatically displays the failure loading speed and finished product count.

Main technical parameters main technical parameter

Power supply	Ac380 volt three-phase five-wire power supply 50 Hz Total power 2.5 kW
Production capacity	Host running speed: 50-100 boxes/min
Air consumption	20 cubic meters / hour (pressure 0.5-0.8 MPa)
Packaging material	Carton requirement	50X20X14mm(LXWXH)
	Specification	Max size: 200X80X50mm(LXWXH)
	Minimum size	50X20X14mm(LXWXH)
Instruction manual	Paper requirement	55-65g/m2
	Specification	Max size: 260X190mm(LXW)
	Minimum size	100x100mm(LXW)
Package size	3250x1450x1550mm
Weight	about 1.2 tone
