Structure features. 1、Introduced touch screen human-machine interface, easy to correct and fine-tune. Alarm and working status can be displayed on the fear you screen, easy to operate and maintain. 2, equipped with the PLC centralized control system of Kunlun Tongtai, Germany SICK photoelectric correction, follow in the accurate printing material, minimize the adjustment and presetting time, improve the production efficiency. 3、Human-oriented safety protection, the whole house design, to ensure the safety of the operator. 4、Automatic unwinding constant tension control, EPC network guide and inverter feeding system, motor, minimizing the network to its adjustment time. 5, high-speed actual, ensure success: suitable for the production of paper range, capacity up to 30 - 150pcs/min, or even higher, increasing the unit production capacity and higher theory. 6, the original German Schneider electrical system, to ensure better stability and reliability, perfect after-sales service, trouble-free for customers.
Technical parameters. Model: with hand-held handle, without hand-held handle Paper bag cutting length: 370-630mm,370-650mm Finished bag width: 230-450mm,230-450mm Bag bottom width: 75-180mm,75-180mm Grammage of raw paper:100-180g/m*m,100-180g/m*m Max. unwind diameter:1500mm,1500mm Max. paper width: 1300mm,1300mm Core inner diameter:3〃,3〃 Max. machine speed:150piece/min,150piece/min Max. bag-making speed:100pieces/min,100pieces/min Total machine power:35kw(48kw with bag mouth press),35kw(48kw with bag mouth press) Machine weight:15000kg,15000kg Overall dimension: L15000*W6500*H2700(bag mouth crimping device length plus 1100mm)
