Main technical parameters:
Punch frequency: 15-40(times/min)
mould cooling: tap water recycle water 60 L/H
max.forming area: 330*110 mm

max forming depth:26mm
stroke: 60-160 mm
compressed air(mpa): 0.6-0.8
total power: 4.5
PVC hard pieces: 0.15-0.5*340
Over dimension: 1900*790*1700 millimeter
weight: 900 kg
