Technical Data: Film:All kind of laminated hot seal film Roll size：Max. Width：1450mm；Max. diameter：φ600mm Bagging speed：150parts/min stand (Real speed look upon material, bag body as a decided) Bagging width：50-500mm(multiple conveying device can be adopted when over long) Bagging length：700mm Bagging data：TFT displaying， punching time can be preset, continuous or interval punching is available. Message alert：lost of photoelectricity, lost of temperature, midway tension and switch off the machine.. Wraping：LPC rectify a deviation, tension is automatically controlled. Feeding：1kw×2=2kw Main engine：3kw×1=3kw Unwind：0.55kw×3=1.65kw Lateral seal：2.5kw×8=20kw Control system etc.：1kw Total：26.55kw Cooling water：15L/min Gas pressure：0.6Mpa Weight：about3500kg Dimension(L×W×H)：10500×1960×2080mm
