High-speed flexographic printing machine for paper
High-speed flexographic printing machine for paper Download Email Print this Page
Products Name :High-speed flexographic printing machine for paper
Specifications
Application characteristics.

This machine is a printing machine with photopolymer soft plate as the plate material, commonly known as

"aniline printing machine". It is suitable for printing polyethylene, polypropylene plastic bags, cellophane, roll

 paper and other packaging materials, and is the ideal printing equipment for food paper packaging, supermarket

 hand bags, horse clip bags, garment bags and other packaging.



Technical parameters.
Max. paper width: 39.96'' (1015mm)
Maximum printing width: 39.37'' (1000mm)
Plate overlap length: 11''-26'' (279.4-660mm)
Maximum unwinding diameter: 60'' diameter (1524mm)
Max. rewind diameter: 60'' diameter (1524mm)
Gear specification: 1/8CP, tooth pitch 3.175mm
Max. machine speed: 500fpm(152m/min)
Drive motor: 11KW
Lubrication system: Automatic lubrication system
Operation console: in front of the printing unit
Air pressure requirement: 100PSI(0.7Mpa)
Power supply requirement: 380V three-phase 50HZ
Suitable printing material: 40-200gsm paper paper printing
Machine color milk white
