Uses. Suitable for the production of BOPP/kraft paper/trademark paper/cloth base/PET/release paper and other adhesive products coated and slit.
Features. Widely adaptable and can be professionally designed according to the nature of substrate. Correcting part: Adopt high sensitivity eight-character infrared correcting instrument. Temperature control: Segmented control, different adjustment according to process requirements. Oven drying: Adopt electrical heating any choice, high drying efficiency. Slitting part: Adopt industrial blade for upper and lower axis automatic slitting. Printing part: Adopt gravure two-color printing. Winding part: Adopting curved guide roller can collect large rolls. Tension control: Adopt magnetic powder tension transverse power control. Gluing part: using comma scraper, adjusting glue pneumatic positioning plus manual fine adjustment.
Main technical numbers. Model: JS-1000B-5500, JS-1000B-7500, JS-1000B-9500, JS-1000B-11500 Effective width: 1000 mm, 1000 mm, 1000 mm, 1000 mm Dimension (L*W*H): 5.6*1.6*2.6m, 7.6*1.6*2.6m, 9.6*1.6*2.6m, 11.6*1.6*2.6m Heating method. Steam/electricity/
