| Technical data： |
|
Technical data HH-500
|
||
|
Sealing type
|
L-sealing by means of L-bar | |
|
Power supply
|
380V/50-60Hz/3phase | |
|
Max Packing capacity
|
35 packs per minute（depends on product size） | |
|
Sealing height
|
≤125mm | |
|
Packing width
|
≤350mm | |
|
Power consumption
|
1.5kW | |
|
Product size
|
width+height≤400mm length+height≤480mm | |
|
Film type
|
center-folded polyolefin（POF）film | |
|
Max film size
|
530mm（width）×280mm（outer diameter） | |
|
Working height
|
780-850mm | |
|
Air pressure
|
≤0.5MPa(5 bar) | |
|
Sealing system
|
permanently heated seal bar coated with Teflon | |
|
Machine material
|
carbon steel | |
|
Weight
|
300kg | |
