Product details 1. Power supply: three-phase 380V,50HZ 2. Total power: 60KW (excluding the power of air compressor) 3. Design speed: 350-400 pieces/min 4. Overall dimension (L×W×H): about 10000×2600×2700MM 5. Qualification rate: ≥98% (excluding material reasons) 6. Maximum width of product: 120MM 7. Operators: 2-3 persons
Features and performance 1. can produce a variety of specifications products, can use the touch screen to adjust the size. 2. Fiber SAP mixing is applied, the amount of SAP is controlled by frequency conversion motor 3. Equipped with high efficiency pulverizer, feeding roller controlled by frequency converter. 4. Evenly shaped wood pulp 5. With wood pulp flat pressing, finished product flat pressing, finished product cutting and other mechanisms 6. Counting output after product forming. 7. The main motor is driven by frequency conversion motor, the transmission system is equipped with closed gear box, universal coupling, imported synchronous belt and chain combination type, high synchronization, stable transmission. 8. The product positioning process is equipped with electric differential gear, which is very convenient to operate and can be adjusted synchronously without stopping. 9. Semi-automatic material receiving device for raw materials. 10. PLC + touch screen + frequency converter system 11. Equipment equipped with product collection system
