Hanging garment bag making machine with roll
Hanging garment bag making machine with roll Download Email Print this Page
Products Name :Hanging garment bag making machine with roll
Specifications
(I), use

With the principle of large arc-shaped bag-making machine, this machine is suitable for making large-size

film packaging bags, narrow-type film bags, as well as the function of making slant-shoulder continuous-roll

 hanging garment bags unique to this machine. The model has beautiful atmosphere, solid structure, smooth

operation, rich and diverse configurations, and has functional plasticity, and can be specially modified to meet

the needs of users.



(II), performance and characteristics
1、 The whole machine adopts microcomputer computer control, stepper motor dragging material. (Optional servo motor control system).
2、 Arbitrary fixed length, step photoelectric tracking, accurate, smooth, automatic shutdown of lost mark, feeding with photoelectric control.
3、 Automatic counting can set the counting alarm.
4、 Automatic constant temperature makes the bag mouth seal firmly and flat.
5、 Before coming out with continuous roll device


(C), the production process.
1. Automatic feeding - import - hot ironing - forming and winding


(D), the main technical parameters.
Machine type: LQ-600mm
Bag-making width: 100-550mm
Bag-making length: 100-3000mm
Production capacity:40m-50m per minute
Total power:4.3kw
Machine weight:650kg
Overall dimension:4000*1230*1500(L*W*H)
