Main features 1. This machine adopts PLC programmed automatic cycle action control, with the functions of stacking, counting, feeding wrapping film sealing and cutting, dividing and so on. (Also can be equipped with automatic code adding machine and date coding machine.) 2. All the important parts are selected from high standard supporting parts, pneumatic components PLC and terminal frequency converter and other electrical appliances are selected from international famous brands. 3. The main machine has compact structure, stable performance, simple operation, double frequency control. Bag length is set that cut, no need to adjust the empty walk, a step in place, save time and film. Positioning stop function, no sticky knife, no film, temperature independent PID control, better for various materials wrapping film. 4. The cup dispensing machine adopts double servo, two-way points, to improve the bagging speed. The production speed is adjustable, and the pointing cup can be selected from 1-100 cups. To achieve the packaging effect. Main technical parameters
Max. film width 450mm Maximum packaging capacity (depending on the material and the number of cups) 30 bags/min Applicable film width 0.03-0.06mm Bag making length 200-1000mm (also can be customized according to customer's requirements) Packaging width 20-220mm Packing height 50--120mm Total power 4kw 220v Machine size 5200×820×1300mm Total weight 800kg
