Model:

TXS-620A

TXS-620B

TXS-720C

Forming sizes(Max):

(W)420-620mm

(L)460-860mm

(W)420-620mm

(L)760-1120mm

(W)420-720mm

(L)760-1220mm

Cooling system:

Blower ×2,

Sprayer×6

Blower×2,

Sprayer×8

Blower×2,

Sprayer×10

Vacuum pump

70 m3/ h（2.8HP）

100 m3/ h（4HP）

100 m3/h （4HP）

Power consumption(Max):

24kw

32kw

38kw

Power supply:

380V/50HZ Three phrases and four wires

Working speed:

200-600 times / hour

Matching air compressor:

7.5-11kw

11-15kw

11-15kw

Overall dimension (mm):

L4800×W1300 ×H2500

L6100×W1300 ×H2500

L6500×W1300 ×H2500

Weight(about):

2T

2.2T

2.5T
