| Type | AZJ-8800Z | AZJ-81000Z | AZJ-81200Z |
| Effective Printing Width | 800mm | 1000mm | 1200mm |
| Max.Width of Web | 850mm | 1050mm | 1250mm |
| Max.Printing Speed | 120m/min | 120m/min | 120m/min |
| Max.Mechanical Speed | 140 m/min | 140 m/min | 140 m/min |
| Max.Diameter of Unwind/Rewind | ф600mm | ф600mm | ф600mm |
| Inside Diameter of Roll Core | ф76mm | ф76mm | ф76mm |
| Diameter of Printing Cylinder | ф140～ф360mm | ф140～ф360mm | ф140～ф360mm |
| Accuracy of Computer Registration | ±0.1mm | ±0.1mm | ±0.1mm |
| Tension Control Range | 20～50kg/Full Width | 20～50kg/Full Width | 20～50kg/Full Width |
| Heating Power of Oven | 120Kw | 144Kw | 234Kw |
| Total Power | 181Kw | 205Kw | 266Kw |
| Weight of Machine | 31000kg | 34000kg | 37000kg |
| Overall Dimension | L20000×W3800×H3100mm | L20000×W4000×H3100mm | L20000×W4200×H3100mm |
