| Type | AZJ-Y6600A | AZJ-Y6800A | AZJ-Y61000A |
| Effective Printing Width | 600mm | 800mm | 1000mm |
| Max.Width of Web | 620mm | 820mm | 1020mm |
| Max.Printing Speed | 60m/min | 60m/min | 60m/min |
| Max.Mechanical Speed | 80m/min | 80m/min | 80m/min |
| Max.Diameter of Unwind/Rewind | ф600mm | ф600mm | ф600mm |
| Inside Diameter of Roll Core | ф76mm | ф76mm | ф76mm |
| Diameter of Printing Cylinder | ф70～ф270mm | ф70～ф270mm | ф70～ф270mm |
| Accuracy of Registration | ±0.2mm | ±0.2mm | ±0.2mm |
| Tension Control Range | 3～25kg/Full Width | 3～25kg/Full Width | 3～25kg/Full Width |
| Heating Power of Oven | 19.2Kw | 24Kw | 28.8Kw |
| Total Power | 23.5Kw | 29.5Kw | 36.5Kw |
| Weight of Machine | 6000kg | 6500kg | 7000kg |
| Overall Dimension | L8500×W2000×H1900mm | L8500×W2200×H1900mm | L8500×W2400×H1900mm |
Performance and Features：
1. The latest improved gear box,360°non-stopping registration device.
2. Movable type doctor blade,transverse reciprocating motion.
3. Far-infrared heating tube drying system.
4. Unwinding and traction adopts magnetic powder brake to make material moving more stable.
5. Rewinding and out feeding adopt magnetic powder clutch.
6. Current output type temperature control system makes heating quicker and electricity saving.
7. Turnover double-station unwinding and rewinding mechanism,receiving and replacing material without stopping the machine.
8. Obverse and reverse side once-through continuous printing.
9. main Motor:electromagnetic speed regulation motor.
