Automatic non-woven apron machine
Automatic non-woven apron machine Download Email Print this Page
Products Name :Automatic non-woven apron machine
Specifications
XK-W600 Automatic Nonwoven Apron Machine Machine Introduction

This new non-woven apron machine has been tested by our engineers and has been running stably. Through

 touch screen automatic control, it can fully automatic complete the steps from non-woven raw material conveying,

folding, cylinder type punching forming, cutting, finished product conveying, etc. High school, stable and durable,

 it is the ideal equipment for fully automatic non-woven apron making.



XK-W600 Full-automatic non-woven apron machine performance and features
1、This machine adopts Taiwan touch screen computer monitor and PLC programmable computer program.
2、Automatic counting, can set any whole number to stop.
3、Any fixed length, printing color scale tracking and positioning, no material automatic stop.
4、High pressure electrostatic processor, automatic constant temperature and temperature control table.
5、Manual tension control of discharge magnetic powder, automatic correction control.
6、Automatic non-woven apron completed at one time, stable bag-making, operation=convenient, beautiful and generous products.


Main technical parameters
 Model XK-W 600
 Max. product width 700mm
 Max. product length 1000mm
 Machine speed 30-40pcs/min
 Applicable material thickness 60-80g
 Power 4.0kw
 Voltage 220V/50HZ
 Machine weight 1200kg
 Machine size 5450*2200*1850mm
